Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: FLUKE
  • Model Number: FLUKE-2042
  • Power: Electronic
  • Usage: Auto Testing Machine
  • Overvoltage category: Cat. III 300 V
  • Transmitter Size: 190 mm x 85 mm x 50 mm
  • Receiver Size: 250 mm x 65 mm x 45mm
  • Transmitter Weight: 0.45 kg
  • Receiver Weight: 0.36 kg
  • OEM/ODM: No

Packaging & Delivery

Packaging Details standard fluke packages
Delivery Time Shipped in 7 days after payment

Fluke-2042 Cable Locator General Purpose Cable Locator Tester Meter Original

Product Description

The Fluke 2042 is a professional general purpose cable locator. It is ideal for tracing cables in walls and underground, locating fuses/breakers on final circuits and locating interruptions and short-circuits in cables and electrical floor heating systems.

It can also be used for tracing metallic water and heating pipes. The unit is supplied as a complete kit comprising of a transmitter and receiver in a purpose-made carry case. The receiver also incorporates a torch function for working in dimly lit locations.

  • For all applications (live or dead cables) without additional instruments
  • Set includes a transmitter and a receiver
  • Proven digitally coded sender signal guarantees clear signal identification
  • Transmitter with LC-display for transmitting level, transmitting code and external voltage
  • Receiver with a backlight LC-display for level of receiving signal, code of receiving signal and live voltage indication
  • Automatic or manual adjustment of receiving signal sensitivity
  • Acoustical receiving signal switchable
  • Auto-Power-Off
  • Additional torch lamp function for working in dark environments
  • Additional transmitters are available for extension of to distinguish between several signals

Technical Specifications

Voltage measurement range

Transmitter: 12 V, 50 V, 120 V, 230 V, 400 V

Frequency range

Transmitter: 0...60 Hz

Output signal

Transmitter: 125 kHz


Transmitter: Up to 400 V AC/DC

Tracing depth cable location

Receiver: 0...2.5 m wall/underground cables

Main voltage detection

Receiver: 0...0.4 m

Environmental Specifications

Operating Temperature


0 to 40°C


0 to 40°C

Storage Temperature


-20°C to +60°C


-20°C to +60°C

Humidity (Without Condensation)


Max. 80% relative


Max. 80% relative

Operating Altitude


Up to 2000 m


Up to 2000 m

Safety Specifications

Electrical Safety

EN 61010-1

Overvoltage category

Cat. III 300 V

Mechanical & General Specifications



190 mm x 85 mm x 50 mm


250 mm x 65 mm x 45mm



0.45 kg


0.36 kg



6 pc Batteries 1.5V


1 pc Battery 9V

Package Includes:

  • 1 x Fluke 2042 Cable Locator
  • 1 x Original Package
  • Additional transmitters are available for extension of to distinguish between several signals
